Genuine DJI D-RTK 3 Multifunctional Station in Genuine OEM condition. Available at AST-Drones for $2,288.00 with fast worldwide shipping. Every unit is inspected by our drone technicians before dispatch.
What’s in the Box
- D-RTK 3 Multifunctional Station × 1
- Spare OcuSync Directional Antennas × 4
- USB-A to USB-C Cable× 1
- Supported Models
Key Features
- Serves as a base station for centimeter-level positioning of multiple drones simultaneously, or as a relay station to extend drone range.
- 1. Measurement accuracy depends on various factors. This value is obtained under normal conditions with an unobstructed view, good satellite distribution, low ionospheric activity, and no electromagnetic interference or multipath effects.
- 2. Intense vibrations and rapid rotations can affect the accuracy of the inertial measurement unit.
- 3. The relay station should be placed in a high, unobstructed location to ensure clear communication between the remote controller and the aircraft.
- 4. Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. Always pay attention to RTH reminders in the app during your flight.
- 5. Please make sure all rubber plug interfaces on the body are properly installed.
Specifications
| GPS | L1C/A, L2C, L5 |
|---|---|
| BDS | B1I, B2I, B3I, B1C, B2a, B2b |
| Galileo | E1, E5a, E5b, E6 |
| GLONASS | L1, L2 |
| QZSS | L1C/A, L2C, L5 |
| Horizontal | 0.8 cm + 1 ppm (RMS) |
| Vertical | 1.5 cm + 1 ppm (RMS) |
| Angle Range | 0°to 60° |
| Horizontal | 8 mm + 0.7 mm/° tilt (accuracy <2 cm within 30°) |
| Protection Rating | IP67 (station only) |
| Diameter | 163 × 89 mm (without OcuSync Directional Antennas) |
| Weight | 1.26 kg |
| Broadcast Mode (Green Light) | Used to provide accurate data for centimeter-level positioning to improve operation precision for multiple DJI aircraft simultaneously. |
| Relay Station Mode* (Blue Light) | After connecting to the specified compatible DJI aircraft and remote controller, installed at a high place and used as a communication relay to avoid signal blockage during operation. |
| Rover Station Mode (Yellow Light) | Used as a handheld mapping device for measuring control points. |
- GNSS Frequency
- L-Band
- Rover Station Mode Accuracy
- Static Measurement
- Tilt Measurement
- Max Transmission Distance (in Relay Station Mode, unobstructed, free of interference)
- FCC:
- 15 km between the aircraft and the relay station
- 1 km between the relay station and the remote controller
- SRRC:
Frequently Asked Questions
What is included with the Genuine DJI D-RTK 3 Multifunctional Station?
The package includes: D-RTK 3 Multifunctional Station × 1, Spare OcuSync Directional Antennas × 4, USB-A to USB-C Cable× 1, Supported Models.
How long does shipping take for the Genuine DJI D-RTK 3 Multifunctional Station?
Orders are processed within 1-2 business days. Delivery typically takes 7-14 days to the US and Europe with tracking provided.
Does the Genuine DJI D-RTK 3 Multifunctional Station come with a warranty?
Yes. All products at AST-Drones are covered by our after-sales support. Contact info@ast-drones.com for any issue and we will make it right.
